Mounted Offset Disc Harrow

Mounted Offset Disc Harrow
The Swan Agro Mounted Offset Disc Harrow is adjustable, allowing farmers to regulate the harrow's depth and angle, catering to various soil types and conditions
Enquiry
Mounted Offset Disc Harrow

Features

  • Frame is made from heavy duty pipe
  • High tensile fasteners are used
  • Disc are made of Boron Steel ,well hardened and tempered.
  • Ideal tillage depth - 125 to 178 mm.
  • Easy mounting and attaching make Swan Agro Harrow ease in transportation.

Advantages

  • Prepares soil for sowing.
  • Burial of stubbles and organic residue in soil.
  • Used in open fields for superficial ploughing.
  • Airing of soil and eliminates weeds , shattering of clods.
  • For breaking the roots of previous crop.
  • Tested and used in extreme conditions.
  • Working angles can be easily adjusted.

Mounted Offset Disc Harrow

Technical Specifications

Description/ Models NSEODH-12 NSEODH-14 NSEODH-16 NSEODH-18 NSEODH-20 NSEODH-22 NSEODH-24
Frame (mm) 75 x 10 angle frame with 100 × 50 channel
Gang bolt / axle (mm) 31 ( Solid Sq. Rod) with split gangs
No. of Disc 12 14 16 18 20 22 24
Type of Disc Notched Disc in front gangs & Plain disc in rear gang
Disc Diameter (mm) 500 × 4 T (22 inch)
Cutting width (mm approx) 1420 1635 1852 2068 2258 2502 2718
Distance between disc (mm) 228
Mounting Category CAT - I / II (Optional)
Bearing Hubs 4 6 8
Weight (Kgs. Approx.) 390 430 500 575 615 676 731
Tractor Power (HP) 30-40 40-50 50-60 60-70 70-80 80-90 90-100
